4 Zone Fire Alarm Panels

1 Piece (MOQ)

Business Type Manufacturer, Exporter, Supplier
Model No PSS – 04Z
Operating voltage Range AC 220v 50Hz ± 10%, DC 24 v 1.5 amp
Operating Temperature -0º C to 50º C
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Operating Humidity
95% (non-condensing)
Hooter Output
1 A (24v DC)
EOL
4k7 ohm, 1 per zone
Construction
1.8 mm CRCA sheet duly power coated
Dimension
H 245mm * W 315mm * D 90mm
Color
Caramel White

The PSS-04Z is an 4-Zone control panel. It is indicating equipment forms the central part of a fire detection and alarm system. The 2-wire is compatible with PSS-04Z devices. And it is the central part of conventional fire alarm system, designed for applications requiring gas leak detector, bell, manual pull stations, and sprinkler supervision. Each zone can be disabled by a button.







Operates on 230 V AC, 50 Hz AC supply



Battery backup with built in charger



Fire, fault status in unambiguous colored LED indications



16 x 2 line dot matrix LCD display



Zone wise fire, open, short LED indications.
