32 Zone Fire Alarm Panels

1 Piece (MOQ)

Business Type Manufacturer, Exporter, Supplier
Model No PSS – 32Z
Operating voltage Range : AC 220v 50Hz # 10%, DC 24V/ 5Amp
Operating Temperature -0º C to 50º (176) C
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Operating Humidity
95% (non-condensing)
Hooter Output
4 A (24v DC)
4k7 ohm, 1 per zone
11 kg
1.8 mm CRCA sheet duly power coated
H 345mm * W 420mm * D 122mm

The PSS-32Z is an32-Zone control panel. It is indicating equipment forms the central part of a fire detection and alarm system. The 2-wire is compatible with PSS-32Z devices. And it is the central part of conventional fire alarm system, designed for applications requiring gas leak detector, bell, manual pull stations, and sprinkler supervision. Each zone can be disabled by a button.


Advance Micro Controller based Fire Alarm Panel.

16x2 Character LCD Display.

Mains, A. C. Fail, fuse, Charging, Rev, Batt. Indication.

Zone wise fire, open, short testing facility.

Zone Wise Hooter option along with common hooter.
